* Output mode:70V, 100V and 4Ω ohms
* Rated power output:30w
* Comes with an interface for 100V constant pressure input ,convenient to integration with the public address system,input volume is adjustable .
* LCD display
* Bluetooth play function
* Mic1 has priotity over other inputs(mute function)
* U disk/SD card(MP3)/FM radio
* 1 mic line and 1 aux line input,and 1 aux output
* LED level indicator
* Mic, line individual volume control
* Treble, bass tone control
* Sofe on power control, Reduce the peak impact on the boot, to reduce noise.
* Short-circuit, over-current, over-load protection.
* Miniature and simple design, stable performance, enough power
* Applications: multimedia classrooms, training rooms, conference rooms, small shops and boutiques, beauty salons and recreational Spaces
Specifications
| Model Number |
CA128U |
|
Rated Power
|
30W |
|
Audio Input
|
Bluetooth/U Disk/SD card/FM/ aux/mic |
|
Signal-to-Noise Ratio（SNR）
|
MIC: 70dB; AUX: 80dB |
|
Total Harmonic Distortion
|
≤ 1% at 1kHz, 1/3 output voltage |
|
Input
|
MIC (unbalanced), AUX (unbalanced) |
|
Frequency Response
|
60Hz-20kHz(±3dB) |
|
Tone Control
|
Bass: ±10dB at 100Hz;
Treble: ±12dB at 10kHz
|
|
Power Consumption
|
|
|
Power Supply
|
|
|
Dimension(L*W*H)
|
260×228×72mm |
| Weight |
3.85kg |
| Warranty |
1-year-warranty |
